Image Sensor |
5 Mega Pixels Color CMOS |
|
Effective Pixels |
2592*1944 |
|
Day/Night Mode |
Yes |
|
IR range |
20m |
|
IR Led |
52pcs 950nm |
|
Memory |
SD Card (8MB – 32 GB) |
|
Operating remote control |
7 button |
|
Lens (Wide lens model) |
F=1.8; FOV=120°; NO IR-Cut-Remove (at night) |
|
Lens (Regular lens model) |
F=1.8; FOV=90°; NO IR-Cut-Remove (at night) |
|
LCD Screen |
2.0” TFT, RGB, 262k |
|
PIR Sensitivity |
3 sensitive levels: High / Normal / Low |
|
PIR distance |
20m |
|
PIR Angle |
90°/120° |
|
Picture size |
5MP/8MP/12MP =2592x1944/3264x2448/4032x3024 |
|
Picture Format |
JPEG |
|
Video resolution |
1080P (1920x1080): 30FPS, 720P (1280x720):30FPS, 640x480 |
|
Video Format |
MOV H.264 |
|
Video Length |
5-30sec. programmable |
|
Shooting Numbers |
1-3 |
|
Trigger Time |
0.6s |
|
Trigger Interval |
3s-60min |
|
Camera + Video |
Yes |
|
Time lapse |
supporting |
|
Timer Setting |
3 Timers |
|
Device Serial No. |
Yes |
|
Built-in Speaker |
Yes |
|
Recording Voice |
ON/OFF |
|
Operation Power |
Battery: 6V; DC: 12V |
|
Battery Type |
12AA |
|
Stand-by Current |
0.035mA |
|
Stand-by Time |
4-8months (4×AA~12×AA) |
|
Auto Power Off |
auto switch to mode “ON” in 60s without any operations |
|
Power Consumption |
IR LEDs Off |
Photo: 200mA; Video: 200mA |
IR LEDs On |
Photo: 1.2A Video: 1.2A |
|
Interface |
TV out/USB/SD Card/DC Port |
|
Mounting |
Strap; Tripod |
|
Storage temperature |
-30 °C to 60°C |
|
Operation Humidity |
5%-90% |
|
Waterproof spec |
IP66 |
|
Dimensions |
11*17*5.5cm |
|
Weight |
500g |
|
Certification |
CE FCC RoHS IP66 |
